EPSITRON® COMPACT(single phase)

Pro Pro 2(1-phase TopBoost + PowerBoost)
IS Series IS Series

Category: Tags: , ,
wago

Description

Features:

  • Switched-mode power supply
  • Stepped profile for installation in standard distribution boards
  • Removable front panel and screw mounts for alternative installation in distribution boxes or devices
  • Pluggable picoMAX® Connection Technology (tool-free)
  • Suitable for both parallel and series operation
  • Electrically isolated output voltage (SELV) per EN 60335-1 and UL 60950-1; PELV per EN 60204

Details:

Input:

Phases 1
Nominal input voltage Ui nom 1 x AC 100 … 240 V
Input voltage range AC 85 … 264 V; DC 125 … 375 V
Input voltage derating -2 %/V (< 100 VAC); -1.33 %/V (< 140 VDC)
Nominal mains frequency range 47 … 63 Hz; 0 Hz
Input current Ii ≤ 1.5 A
Discharge current ≤ 0.25 mA
Inrush current ≤ 20 A
Power factor ≥ 0.5
Power factor correction (PFC) Passive
Mains failure hold-up time ≥ 60 ms

Output:

Nominal output voltage Uo nom DC 24 V (SELV)
Output voltage range DC 22 … 26 V (adjustable)
Default setting DC 24 V
Nominal output current Io nom 2.5 A; 2 A (< 110 VAC)
Nominal output power 60 W
Control deviation ≤ 1 %
Deviation, dynamic load change 10 … 90 % ≤ 1 %
Residual ripple ≤ 100 mV (peak-to-peak)
Overload behavior Constant power
(in overload range: 1.05 … 1.35 x Io nom);
Shutdown and automatic restart in the
event of a short circuit or permanent overload
